SESTOS D1S-2R-24 Digital PID Temperature Controller, AC/DC 12-24V, -50 to 1300℃, Multi Sensor Input K J PT100, Relay Output Alarm
Digital PID Temperature Controller
$42.99
Out of stock
Universal Multi-Sensor Input Compatibility：This digital PID temperature controller supports a wide range of sensor inputs including K, S, Wre, T, E, J, B, N, CU50, and PT100, making it adaptable to diverse industrial heating and cooling applications.
Wide Temperature Control Range & High Accuracy：With a measurement range of -50 to 1300℃ (using K-type sensor), the D1S-2R-24 delivers precise regulation with an indication accuracy of 0.1℃ and control accuracy of ±0.2% FS, ensuring stable process temperatures.
Flexible PID and ON/OFF Control Modes：Users can select between advanced PID auto-tuning for smooth, steady control or simple ON/OFF control for basic applications, providing flexibility for both complex automation and straightforward switching tasks.
Built-in Digital Filter & Auto-Tuning Technology：The integrated digital filter effectively reduces electrical interference for reliable performance. Auto-tuning technology simplifies initial setup, while the parameter lock function prevents unauthorized setting changes.
Clear Display & Compact DIN Mount：Features a bright, user-friendly digital display for clear temperature readings. The standard DIN 48x48mm panel mount design fits easily into existing control cabinets, with dual relay outputs (Control + Alarm) for integrated system protection.
The SESTOS D1S-2R-24 is a versatile digital PID temperature controller designed for precise thermal management in industrial automation. Housed in a compact DIN 48x48mm enclosure, this controller accepts universal inputs from thermocouples (K, J, S, E, etc.) and RTDs (PT100, CU50), covering a broad temperature range from -50 to 1300℃ (K sensor).
Equipped with both PID (with auto-tuning) and ON/OFF control modes, the D1S-2R-24 offers exceptional flexibility for applications ranging from plastic extrusion to HVAC systems. The clear LED display provides accurate readings with 0.1℃ resolution and ±0.2% FS control accuracy. A built-in digital filter minimizes interference, and the parameter lock secures your settings. Powered by a universal AC/DC 12-24V supply and featuring dual relay outputs (one control, one alarm), this controller is a reliable solution for temperature regulation tasks.
